SounDigital 2000.2 EVO 5 - 2 Ohm

The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects. Specifikation Power @ 1Ω: 2 X 1000W Power @ 2Ω: 2 X 660W Bridge Power @ 2Ω: 1 X 2000W Bridge Power @ 4Ω: 1 X 1320W Frequency Response (-3dB): 10Hz ~ 20kHz Low Pass Filter (LP -12dB/8): 80Hz High Pass Filter (HP -12dB/8): 80Hz Operating Voltage: 8V ~ 16V SNR: 90dB Input Sensitivity: 0.2 ~ 4V Current Draw (Music): 2Ω: 89A 4Ω: 88A Current Draw With Resistive Load (1kHz @ 12.6V): 2Ω: 178A 4Ω: 176A Total Efficiency: 2Ω: 89% 4Ω: 90% Damping Factor (@100Hz Rated Impedance): 200 Minimum Audio Output Impedance: 2Ω: 1 ohm 4Ω: 2 ohms Minimum Bridge Impedance: 2Ω: 2 ohm 4Ω: 4 ohms Recommended Fuse (Music): 100A Recommended Battery (Music): 100Ah Width: 5.4 in / 13,6 cm Length: 8.9 in / 22,7 cm Height: 2.2 in / 5,5 cm Weight: 3.39 lb / 1,54 Kg
