DD Audio M5a

The latest revisions of the M5a amplifiers push the design limits of the traditional M Series circuit as far as it can go. Internally the power supplies have been optimized to better support the immense internal power demands when listeners push their system to the edge of its capability. Externally the chassis has been revised for better cooling and optional aesthetic upgrades. These amps are also the first offerings from DD to be ZVL ready making multi amp systems easier to set up and control. Features: Optimized High Current Power Supply ZVL Linking Module Input 24dB/Oct Bandpass Filters Improved Cooling Custom Vanity Plate Ready Remote w/ LCD Voltage Display and Clipping Indicator Operating Voltage: 9 - 16v Test Voltage: 14.4 Channels: 1 Cont Wattage @ 4ohm: 2800 Cont Wattage @ 2ohm: 5000 Cont Wattage @ 1ohm: 8000 Dynamic Wattage: 10000 Max Current Wattage Draw – Amps: 800 RCA Input Sensitivity (Volts): 8v - 0.2v Frequency Response: 13Hz - 208Hz RCA Input S/N: 96dB Damping Factor: 210 Pass-Through Output: No Remote Subwoofer Control: Yes (Remote Included in Box) Power Wire Gauge – In: 3 x 0 Speaker Wire Gauge – Out: 10 Dimensions (mm): 698.5 x 228.6 x 66.04
