Rotel RC-1572 MKII

Dimensions (W × H × D) 431 × 99 × 338mm Front Panel Height 2U / 88.1mm (3.5") Power Requirements 230V, 50Hz Power Consumption 35W Standby Power Consumption <0.5W Net Weight 7.4kg BTU Rating 65 BTU/h Total Harmonic Distortion (THD) (20Hz–20kHz) <0.004% Frequency Response Line Level Inputs: 10Hz - 100kHz ±0.3dB Digital Inputs: 20Hz - 20kHz ±0.5dB Phono Input: 20Hz - 20kHz ±0.3dB S/N Ratio (IHF "A" Weighted) Line Level Inputs: 110dB Digital Inputs: 100dB Phono Input: 80dB Intermodulation Distortion (60Hz:7kHz, 4:1) <0.004% Input Sensitivity Line Level Inputs (RCA): 200mV Line Level Inputs (XLR): 300mV Phono Input (MM): 3mV Input Impedance Line Level Inputs (RCA): 100kΩ Line Level Inputs (XLR): 100kΩ Digital Inputs: 75Ω Phono Input (MM): 47kΩ Input Overload Line Level Inputs: 4V Phono Input: 62mV Output Level Unbalanced (RCA): 1V Balanced (XLR): 2V Tone Controls ±10dB at 100Hz / 10kHz Coax/Optical Digital Input Signals LPCM (Up to 24-bit/192kHz) PC-USB USB Audio Class 1 (up to 24/96) USB Audio Class 2 (up to 32/384)* Driver Installation Required DSD/DoP 1x, 2x
