Rotel RC-1590 MKII

Dimensions (W × H × D) 431 × 144 × 348mm Front Panel Height 3U / 132.6mm (5.25") Power Requirements 230V, 60Hz Power Consumption 45W Standby Power Consumption <0.5W Net Weight 9.2kg BTU Rating 78 BTU/h Total Harmonic Distortion (THD) (20Hz–20kHz) <0.002% Frequency Response Line Level Inputs: 10Hz - 100kHz ±0.1dB Digital Inputs: 20Hz - 20kHz ±0.5dB Phono Input: 20Hz - 20kHz ±0.2dB S/N Ratio (IHF "A" Weighted) Line Level Inputs: 112dB Digital Inputs: 108dB Phono Input: 80dB Input Sensitivity Line Level Inputs (RCA): 150mV Line Level Inputs (XLR): 250mV Phono Input (MM): 2.5mV Input Impedance Line Level Inputs (RCA): 100kΩ Line Level Inputs (XLR): 100kΩ Digital Inputs: 75Ω Phono Input (MM): 47kΩ Input Overload Line Level Inputs: 4V Phono Input: 30mV Output Level Unbalanced (RCA): 1V Balanced (XLR): 2V Channel Separation Line Level Inputs: >75dB Phono Input: >75dB Tone Controls ±10dB at 100Hz / 10kHz Coax/Optical Digital Input Signals LPCM (Up to 24-bit/192kHz) PC-USB USB Audio Class 1 (up to 24/96) USB Audio Class 2 (up to 24/192)* *Driver Installation Required DSD/DoP 1x, 2x
